Collective Thermostatic Heating Magnetic Stirrer

Date:2024-06-06 Source:

产品特点(Features):

●Using a collector heating method, the heated container is completely exposed to strong thermal radiation, and the heating speed is three times that of other planar heating magnetic stirrers. Uniform temperature, high efficiency, more suitable for heating reactions in spherical flasks.

●The main components of this machine are made of excellent materials, and the motor is a high-power DC motor with high mixing torque and low noise. Specially made stainless steel heating tubes are aged at a high temperature of 800C for 24 hours. Insulation resistance>1000MQ, safe and reliable during dry burning. The magnetic steel uses the currently strongest "neodymium iron boron" permanent magnet as the rotor to ensure sufficient suction and torque.

●The structure is reasonable, and the collector pot is made of high-quality stainless steel stamping, combined with special heating pipes and high- temperature sealing. It can add water (water bath), oil (oil bath), and dry burn, which are also the main advantages of this machine. The heating part is separated from the electrical box by a heat dissipation plate, and under high- temperature heating and stirring, it does not affect the electrical performance of the entire machine. According to user requirements. Customized large and small capacity collector stirrers.



技术参数(Technical data)
型号(Model ) 东风-101S
特征(Characteristic) 智能(Intelligent)
搅拌容量(Mixing capacity) 最大2000ml (Max2000ml)
搅拌速度(Stirring speed) 无极调速0-2600 (Stepless regulation0-2600)
加热温度(Heating temperature) 室温~400°C( Room~temperature)
控温方式(Temperature control) 智能自动( lntelkigent automatic)
工作电压(Working voltage) 220V/50赫兹
整机尺寸(Dimensions) 239毫米*245毫米*220毫米
零售价(Retail price) 人民币 1040
